1.5mm Thickness Power Bank Pcb Layout Metal Core Pcb Manufacturer

I'm Online Chat Now

Power Bank PCB

Power Bank PCB Sample Introduction

1.5mm Thickness Power Bank Pcb Layout Metal Core Pcb Manufacturer

China 1.5mm Thickness Power Bank Pcb Layout Metal Core Pcb Manufacturer Supplier
1.5mm Thickness Power Bank Pcb Layout Metal Core Pcb Manufacturer Supplier 1.5mm Thickness Power Bank Pcb Layout Metal Core Pcb Manufacturer Supplier 1.5mm Thickness Power Bank Pcb Layout Metal Core Pcb Manufacturer Supplier 1.5mm Thickness Power Bank Pcb Layout Metal Core Pcb Manufacturer Supplier 1.5mm Thickness Power Bank Pcb Layout Metal Core Pcb Manufacturer Supplier 1.5mm Thickness Power Bank Pcb Layout Metal Core Pcb Manufacturer Supplier 1.5mm Thickness Power Bank Pcb Layout Metal Core Pcb Manufacturer Supplier

Large Image :  1.5mm Thickness Power Bank Pcb Layout Metal Core Pcb Manufacturer

Product Details:

Place of Origin: China
Brand Name: VENTEC
Certification: UL ROHS 94V-0
Model Number: VT-4A2

Payment & Shipping Terms:

Minimum Order Quantity: 1 piece
Price: 200-500 usd/ sq. m
Packaging Details: Vacuum
Delivery Time: 12-15 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000 sq.m per month
Contact Now
Detailed Product Description
Material: VT-4A2 Alu Thickness: 1.5mm
Cu Thickness: 2/0oz Thermal Conductivity: 2.2w/mk
Soldermask: Tamura Dsr-2200 Legend: PSR-4000
Surface Finished: Immersion Gold. OSP
High Light:

power bank circuit board

,

mobile power bank circuit board

Pcb power bank power bank board Metal core pcb manufacturer MCPCB power bank pcb layout



PCB Type Material Type Material Brand
Single side pcb
Double side pcb
Multilayer pcb
Single side pcb
CEM-1
FR-4
Aluminum
Copper
Ceramic
SY
KB
IL
LianMao
HongRen
Arlon
KingWong
VT
Laird
5052 Series

The advantage of us
1 We have our own, independent of the wastewater treatment system.Make sure there will be a very big development space and the stability of the production environment in the futurer
2 Flexible operation, can be in the production of small batches.Also can produce large quantities.Can save production quickly.
3 The urgent double sample production for 24 hours, The urgent Multilayer sample production for 48 hours.completely according to customer requirements
About the Files
1 You have gerber files or PCB files
2 You have PCB samples. send to us the sample. we will help for free copy it

How to calculate the price
1 For example, your double sided PCB size is 100 mm * 200 mm wide, long double sided PCB price is $60 a square meters.So the calculation results 100MM*200MM*$60/1000000=$1.2
1 inch=25.4mm

About the transportation.
All the quotation does not include the transportation cost

1 You find a freight forwarding company to help you, When we finished the PCB ,We wiill send to your forwarder company directly .You directly to the transport charges paid to forwarder company
2 We help you responsible for transport, freight included in the price.According to how much money a kilogram computation.
3 In order to save costs.The best is you have familiar forwarder company

Factory is specialized in ceramic circuit boards, copper base PCB, mirror aluminum circuit boards, high thermal conductivity aluminum substrate PCB products such as research and development and production, product features in addition to the insulation layer thin, small heat resistance, nonmagnetic, good heat dissipation, high mechanical strength, work also has a good reliability, long service life.As a result, they are widely used in COB packaging, high-power LED lighting, high-power power supply, engineering installation of lamps and lanterns, commercial lighting, household lighting lamps and lanterns, and other areas of the green lighting.



Process Capability

Material Type: FR4/Aluminum/Ceramic/CEM-1/Copper/polytef Cooper thickness: 0.5-12OZ
Board Thickness: 0.2-6.0mm Min hole size: 0.25mm( finished hole size)
Min Line Width/spacing:0.08mm Drilling accuracy:+/-0.05
Max working size:520*620mm(21.25x24.5inch) Min Inner layer thickness:0.1mm
Min thickness Board for HAL surface finished:0.4mm Certificate: Rohs, Iso9001, UL(in certification)
Min thickness 4 layer: 0.4mm Min thickness 6 layer:0.6mm
Min/Max layer count : 1/20 Lamination evenness :+/-0.05mm
Min SMD Pitch : 0.125mm Min Dam Between Fine Pitch: >0.1mm
Layer to Layer registration:<0.1mm Impedance control:+/-5%
Differential impedance:+/-10% Board bow/twist tolerance:<0.7%
Plating spect ratio: <8:1 Plating COV: <10%
Surface Finished: LF-HASL ,Immersion Gold/Tin/Silver ./Plating Gold/OSP, PTH backlight : 9-9.5 level
Solder Mask:Green , Red, Blue,White, Black,Yellow. Plating extensibility:>15%
